SYSTEM SPECIFICATIONS
|
| Automatic front and back |
A5-SRA3; 52-256 gsm |
| System memory |
2048 Mb |
| Hard disc Interface |
250 Mb 10-Base-T/100-Base-T/1,000-Base-T Ethernet; USB 2.0 |
| Network protocols |
TCP/IP (IPv4 / IPv6); IPX/SPX; NetBEUI; AppleTalk (EtherTalk); SMB; LPD; IPP; SNMP; HTTP |
| Document feeder automatic |
RADF up to 80 ipm colour/b/w - 100 originals R-ADF, Dualscan ADF (optional) |
| Paper format |
A6-SRA3, customised paper format; Banner paper max 1.200 x 297 mm |
| Paper density |
52-300 gsm |
PRINTER
|
| Print resolution |
1,800 equivalent x 600 dpi, 1,200 x 1,200 dpi |
| Controller CPU Type |
PowerPC MPC8536 @ 800 MHz |
| Description language page |
PCL 6c (PCL 5c + XL3.0), PostScript 3 (CPSI 3016), XPS |
| Operating system |
Windows 2000/XP/XP64, Windows VISTA 32/64, Windows 7 32/64, Server 2000/2003/2003x64/2008/2008x64/200 (R2) Macintosh 9.x /10.x Unix / Linux /Citrix |
| Printing fonts Printing functions |
80x PCL Latin; 137x PostScript 3, Emulation Latin Direct print of PCL, PS, TIFF, XPS, PDF and encrypted PDF files, Mixmedia and Mixplex, “Easy Set” programming, Overlapping, Watermark, Copy protection |
SCANNER
|
| Scanning speed (B/W and colour) |
Up to 160 ipm (with DF-701) / Up to 80 ipm (with DF-624) |
| resolution Scanning |
Max.: 600 x 600 |
| Modes |
Network TWAIN scan; scan-to-eMail (scan-to-Me); scan-to-FTP; Scan-to-SMB (scan-to-Home); scan-to-Box; scan-to-WebDAV; scan-to-DPWS; scan-to-USB |
| File formats |
JPEG; TIFF; PDF; PDF/A 1a and 1b (optional); Compact PDF ; Encrypted PDF; Searchable PDF (optional); XPS; Compact XPS; PPTX and Searchable PPTX (optional) |
| Scan destinations |
2,100 (single + group), LDAP support |
COPIER
|
| Printing process |
Electrostatic laser copy, Tandem indirect |
| Toner type |
Polymer toner, chemical |
| Warm up time |
Approx 20 (warm up times can vary with type of use) |
| Copy resolution |
600 x 600 |
| Gradations |
256 gradations |
| Original format |
A5-A3 |
| Enlargement |
25-400 % in steps of 0.1 %; Automatic zoom |
| Copy function |
Heading, inserting page and cover, test run (print and display), test run setting, creative digital functionality, setting job memory, poster mode, image repeat, overlapping, watermarks, stamps, copy protection, membership card copy |
USER BOX SPECIFICATION
|
| Max box memory |
Up to 3,000 documents or 10,000 pages |
| Type of box system |
Public, Private (with password or authentication); Group (with authentication) Secure printing, Encrypted PDF printing, Fax receipt, Fax polling |
| User box functionality |
Reprint, combination, download, send (e-mail, ftp, smb and fax), box to box copy |
FAX (tillval)
|
| Standard Fax |
Super G3 (optional |
| Transmission Fax |
Analogue; i-Fax; Colour i-Fax (RFC3949-C); IP-Fax; SIP-Fax |
| Resolution Fax |
Max.: 600 x 600 (ultra-fine) |
| Compression Fax |
MH; MR; MMR; JBIG |
| Modem Fax |
Up to 33.6 |
| Destinations Fax |
2,100 (single + group) |
| Functions |
Polling; Time shift; PC-Fax; Reception in reserved boxes; Reception via email/FTP/SMB; up to 400 job programs |
